Pultrusion Resin
Pultrusion Resin — 71/77/78 Series
High-reactivity, low-shrinkage unsaturated polyester resins optimized for the pultrusion process. From fast-line-speed grating production to high-temperature epoxy-modified profiles, these grades deliver excellent glass wet-out, consistent curing, and superior mechanical properties.
Pultrusion 拉挤
Grating 格栅
Cable Tray 电缆桥架
Profiles 型材
Product Overview
Our Pultrusion Resin series provides five specialized grades for continuous fiber-reinforced profile manufacturing. The high-reactivity AT-PUL-02 delivers maximum line speed for standard profiles, while the thixotropic AT-PUL-03 handles complex angled and irregular cross-sections without sagging. The AT-PUL-04 combines medium viscosity with excellent water and weather resistance, ideal for outdoor installations. For surface-critical applications, AT-MAR-03 offers low shrinkage and low wave for premium surface quality. The epoxy-modified AT-PUL-01 provides the ultimate heat resistance with HDT ≥120°C for demanding environments.
Technical Specifications
| Grade | Viscosity (mPa·s, 25°C) |
Gel Time (min, 25°C) |
Tensile Strength (MPa, ≥) |
Flexural Strength (MPa, ≥) |
HDT (°C, ≥) |
Features |
|---|---|---|---|---|---|---|
| AT-PUL-02 | 650–900 | 4–10 | 65 | 120 | 110 | 高反应活性 / 中等粘度 / 拉挤速度快 |
| AT-PUL-03 | 800–900 | 9–10 | 45 | 95 | 85 | 触变型 / 斜面异型材拉挤 / 低流挂 |
| AT-PUL-04 | 600–800 | 10–15 | 73 | 108 | 68 | 中等粘度 / 高反应活性 / 耐水耐候 / 光泽度高 |
| AT-PUL-01 | 900–1100 | 4–10 | 70 | 120 | 120 | 环氧改性 / 耐热性好 / 机械强度高 |
* Test conditions: 25°C, standard MEKP promoter. AT-PUL-04 solid content 65-71%. Contact us for full TDS.
▶▼ Complete Technical Data Sheet (TDS) 完整技术数据
| 牌号 | Acid Value (mgKOH/g) |
Solid Content (%) |
Stability @80°C 80℃稳定性 (h) |
Curing System | Packaging | Storage |
|---|---|---|---|---|---|---|
| AT-PUL-02 | 18-24 | 60-66 | ≥24 | 100g树脂 + 1% Co + 2% MEKP HBO-50 | 220KG金属桶 | 20℃下6个月，30℃下3个月 |
| AT-PUL-03 | 18-24 | 65-72 | ≥24 | 100g树脂 + 1% Co + 2% MEKP HBO-50 | 220KG金属桶 | 20℃下6个月，30℃下3个月 |
| AT-PUL-04 | 16-21 | 65-71 | ≥24 | 100g树脂 + 1g MEKP + 0.5g 钴水 (25℃) | 220KG金属桶 | 3 months at 25°C |
| AT-PUL-01 | 18-24 | 65-72 | ≥24 | 100g树脂 + 1% Co + 2% MEKP HBO-50 | 220KG金属桶 | 20℃下6个月，30℃下3个月 |
Data tested per GB standards at 23±2°C, 50±5% humidity. Curing conditions may vary by application. Contact us for detailed processing guidance.
